Barnard 150 Seahorse Nebula

Constellation: Cepheus        Distance: 1200 lightyear

Seahorse Nebula

Click for full resolution (6209 x 7441)

De Zeepaardnevel is een donkere nevel die opvalt als een inktzwarte figuur tegen de sterrenrijke Melkweg. Het is een enorme interstellaire stofwolk die het licht van achterliggende sterren volledig blokkeert. De afmeting is ongeveer 1 graad aan de hemel (twee keer zo groot als de volle maan). Om dit Zeepaardje in beeld te krijgen is een mozaïek gemaakt van drie verschillende opnames. De nevel wordt Barnard 150 geneomd, de 150e in de beroemde catalogus van E.E. Barnard, en staat ook bekend als LDN 1082 in de Lynds-catalogus.


Image spcefications:
  • Exposure: 11.5 hours, LRGB = 540:90:90:90
  • Camera: ZWO ASI2600MM, Temp -10 ° C, Baader LRGB filters
  • Instrument: TEC 140, focal distance 980 mm
  • Mount: Paramount MX+
  • Guiding: TS Off Axisguider, Starlight Xpress Lodestar autoguider and PHD
  • Location: Nozières, France
  • Ambient temperature: 25° C
  • Date: 21, 22 and 23 August 2023
  • © Frans Kroon, Arno-MarkBlesgraaf

Image acquisition Sequence Generator Pro:
  • 3 panel mosaic: 54 Luminance of 10 minutes, binned 1x1
  • 3 panel Mosaic: 18 Red + 18 Green + 18 Blue of 5 minutes, binned 1x1
  • 25 Flat fields per channel with Flatfield panel
  • 20 Dark frames of 10 minutes + 20 Dark frames of 5 minutes + 50 Bias frames

Processed with PixInsight 1.8.9-2:

    Lineair:
  • ImageCalibration and StarAlignment
  • ImageIntegration and ChannelCombination RGB
  • GraXpert on Lum and RGB
  • ImageSolver and SPCC on RGB
  • BlurXTerminator on Lum and RGB

  • Non Lineair:
  • HistogramTransformation on Lum and RGB
  • NoiseXTerminator on Lum and RGB
  • LRGBCombination

  • For Mosaic:
  • ImageSolver (list to make WCS)
  • MosaicByCoordinates (to make WCS_registered)
  • GradientMergeMosaic

  • StarXTerminator with Generate StarImage
  • CurvesTransformation on starless photograph
  • MorphologicalTransformation (smaller stars) on StarImage
  • CurvesTransformation (more color in stars) on StarImage
  • PixelMath to put them together
